12VDC Micro Electric Linear Actuator 150N High Thrust Power 10mm-200mm Adjustable Stroke

Product Details:

Place of Origin:	China
Brand Name:	MaxM
Model Number:	LS-TB-N

Payment & Shipping Terms:

Minimum Order Quantity:	10
Packaging Details:	Carton
Delivery Time:	2 weeks
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	2000pieces/Month

Contact Now

Detailed Product Description

Name:	Micro Electric Linear Actuator	Voltage:	6V / 12V / 24V DC
Max. Load Force:	15Kg	Duty Cycle:	10%
Life Cycles:	＞20000 Cycles	Stroke:	10- 200mm
IP Rating:	IP43	Limit Switch:	In Built
Signal Output:	Without
Highlight:	12VDC Micro Electric Linear Actuator , Micro Electric Linear Actuator 150N , 12v Micro Linear Actuator High Thrust

12V DC Micro Electric Linear Actuator 150N High-Thrust Power 10mm-200mm Adjustable Stroke

This micro actuator is designed for precise and reliable linear motion in space-limited applications. It offers multiple speed-and-force combinations to suit different load requirements. Its aluminum inner tube, IP43 protection, and stable operation make it well-suited for light-duty automation, furniture, and small industrial applications.

Specifications:

Model	LS-TB-N
Voltage	6V / 12V / 24V DC
Duty cycle	10% (Max.2Min ON/18Min OFF)
Max.Load Force	150N
Cycle life	≥20000 cycling times
Stroke	10mm- 200 mm
Working temperature	0°C ~ +40°C
IP rating	IP43
Limit switches	Built-in
Materials	Aluminum , Plastics

Features:

Compact & Space-Saving Design
Reliable Self-Locking Performance
Stable & Durable Construction
Multiple Speed & Load Options

Questions and Answers:

Q: Is it possible to get a sample?

A: Yes, we can provide samples for quality and performance testing.

Q: Is the product ready for dispatch?

A: No. For bulk orders, the standard lead time is approximately two weeks. The exact timeline is contingent on raw material availability.

Q: Do you provide after-sales service?

A: Yes. We offer technical support and prompt after-sales service. Please feel free to contact us if you have any questions.

Q: What payment methods do you accept?

A: We accept bank TT, L/C, and PayPal
